Archived

DSW-1H

Name: DSW-1H
Brand: Denon
SKU: 137290-01-00-101

Subwoofer with HEOS® Built-in

The Denon DSW-1H wireless subwoofer connects via Wi-Fi to the Denon DHT-S716H sound bar, Denon Home Sound Bar 550, or any Denon Home speaker, to add deep, powerful bass you can feel and hear.

Select Quality

Color

Black

DSW-1H

Details & Specifications

Information Sheet

Audio System

Adjustments Subwoofer level Factory-optimized crossover option for each configuration Advanced settings like crossover and phase for advanced users
Combinations The DSW-1H can be combined with the following products: DHT-S716HHEOS AVRHEOS Amp and HEOS Link Any HEOS speaker (single or stereo pair)
Speaker System Dual Custom 5-1/4 inch drivers Sophisticated, high power Class D amplifier Low resonance cabinet Optimized tuned port

General

Controls and Indicators Volume Up/Down (+, -), Mute, Mute LED indicator
Dimensions (H x W x D) Vertical placement: 16 x 6 7/8 x 17 3/8 inches;404 x 171.5 x 438.4 mm
Multiple Language Support English, French, Spanish
Operating Temperature Range 41°F~95°F; 5°C~35°C
Power Supply 120 Volts AC, 60 Hz
Product Finish Black
Weight 22.27 lbs; 10.1 kg
What's In The Box DSW-1H, Quick Start Guide, 3.5mm setup cable, Power Cord, Ethernet cable, Feet for horizontal setup

Music Sources

Internet Radio Stations Choose from your favorite internet radio stations and listen to MP3, AAC and WMA (via the TuneIn service).
Music Formats Supported WMA: Up to and including 192kbpsAAC and MP3: Up to and including 320kbpsFLAC, WAV and ALAC: Up to and including24-bit/192kHzDSD 5.6MHz
Music Subscription Services The HEOS App lets you choose from popular subscription streaming services including Rhapsody, Pandora, Spotify and TuneIn, iHeartRadio, SiriusXM, MOOD:MIX and from other services that offer DRM-free tracks. More services will be added soon.*
Picture Formats Supported HEOS App supports JPG, PNG, BMP and GIF album art picture formats.
USB Drives Supported DSW-1H supports USB thumb drives via the built-in USB port. Music content on a USB drive can be played back locally, or on any or all HEOS players on your network. *Availability of music services may vary by region. Not all services may be available at time of purchase. Some services may be added or discontinued from time to time based on decisions of the music service providers or others. Visit usa.denon.com/us/heos for announcements and details.

Networking

Wired Connection Connect to your home or office LAN system via the RJ-45 wired LAN port.
Wireless Connection Connect to your wireless network quickly and easily. DSW-1H supports the latest 802.11 networks (including dual band "N", "AC") for the most reliable network connection.
