DRA-800H

Name: DRA-800H
Brand: Denon
SKU: 137271-01-00-101

2.2 Ch. 100W 4K AV Receiver Powered by HEOS™

Denon stereo receiver built with Hi-Fi amplification seamlessly integrates with the latest Hi-Res audio, wireless, voice control and AV receiver technologies including five 4K Ultra HD HDMI inputs.

Select Quality

Color

Black

DRA-800H

Details & Specifications

Multichannel Surround

DTS HD Master / DTS:X No / No
DTS Neo:X / DTS Neural:X No / No
DTS Virtual:X No
IMAX Enhanced No
Dolby TrueHD / Dolby Atmos/Dolby Atmos Height Virtualization No / No / No
Dolby ProLogic Ilz / Dolby Surround No / No
Auro 3D No
Audyssey DSX No
Multichannel Stereo No
Max Number of Processing (Preamp) Channels 2.1

Sound Enhancements

Mono Block Power Amp Construction No
Discrete Power Amplifier Yes
D.D.S.C. HD Digital No
Pure Direct Yes
Gold Plated RCA Terminals Yes
Clock Jitter Reducer No
Alpha Processing No
Denon Link HD No
Audyssey No
Audyssey Dynamic EQ / Dynamic Volume No / No
Audyssey LFC No
Compressed Audio Restorer Yes

Network

Media Server Yes
HEOS Wireless Multi-Room Technology Yes
Bluetooth Re-transmit for Bluetooth headphones Yes (update)
Alexa / Google Voice Assistant / Apple HomePod Yes / Yes / Yes
Lossy Formats: MP3 / WMA / AAC Yes / Yes / Yes
Lossless Formats: FLAC / ALAC / WAV Yes / Yes / Yes
DSD Audio Streaming Yes (2.8/5.6MHz)
FLAC HD 192/24 Yes
WAV 192/24 Yes
ALAC 192/24 Yes
Gapless playback Yes (FLAC, WAV ,ALAC ,DSD)
Photo Streaming (JPEG) No
Internet Radio Yes (TuneIn)
Spotify* Yes (connect)
Pandora Yes
SiriusXM* Yes
Other Streaming Services * Amazon Music / TIDAL / Deezer / iHeart Radio / Napster / Soundcloud / Mood Mix
HEOS App Control Yes
Compatible with Remote APP for Smart Phones Denon 2016 AVR Remote
Compatible with Remote APP for Tablets Android / iOS / Amazon Kindle
Ethernet Ports Yes
Wi-Fi Yes
Bluetooth Yes

HDMI

HDMI Inputs: Back / Front 5 / No
HDCP 2.2 support Yes (HDCP 2.3)
HDMI Outputs: Main / Zone 1 / No
Video Conversion Analog -> HDMI No
Analog to HDMI Scaling No
HDMI to HDMI Scaling No
GUI Overlay on HDMI Yes
HDMI: 3D / 4K / CEC / ARC / InstaPrevue Yes / Yes / Yes / Yes / No
Enhanced ARC No
HDR / HLG / Dolby Vision Yes (HDR10) / Yes / No
ALLM (Auto Low Latency Mode) Pass-through for gaming Yes
3D Signal Pass-through Yes
4K Signal Pass-through / Scaling / GUI Overlay Yes / No / Yes
HDMI Pass-Through in Standby Mode Yes
Picture Adjust / Noise Reduction No / No
CEC Yes
DSD Audio Capability No
Audio Return Channel Yes
Auto LipSync Yes

Multi-room CI

Multi-Room Zones 2
Zone Audio Source: HDMI / Opt, Coax / Network, USB / Analog Yes (2ch) / Yes (2ch) / Yes / Yes
Zone Audio Output: Speaker / Preout No / Yes
Zone HDMI Output from HDMI Source No
IP Control / RS232 Control / Web Control / App Control Yes / No / Yes / Yes
Remote In / Out Yes / No
DC Trigger Output No
HDMI Diagnostics Yes

Others

Auto Speaker Setup by Microphone No
FL Display 1 line
Graphic User Interface - GUI Hybrid GUI
ISF Certification No
GUI Languages 3
Setup Assistant Yes
Quick Select Plus / Quick Select Yes / No
Firmware Update by: Network / USB Yes / Yes
Variable Cross Over No
Optimized Bass Redirection No
Bass Sync No
ECO Mode Yes
Auto Power Off Yes
Sleep Timer Yes

Inputs Outputs

Composite In / Out No / No
Component In / Out No / No
HDMI In / Out 5 / 1
Multi-room Video Out: Video / HDMI No / No
2 / No
Phono (MM) In Yes
Digital In: Optical / Coaxial 2 / 1
Multi-room Out: Analog / Digital 1 / 0
Multichannel Preout Yes (0.2) / No
Subwoofer Out 2
7.1 Multichannel Input No
Speaker Terminal: Gold Plated Screw / Regular Screw Yes / No
Number of Speaker Terminals 4
Speaker A / B Yes
Bi-amp Drive No
Multi-Room Speaker Terminal No
Front Inputs: Audio / Composite / Digital (Opt) / HDMI / USB No / No / No / No / Yes
USB Audio / Made for iPod / Made for iPhone Yes / No / No
AM/FM Tuner Yes

Specifications

Number of Power Amps 2
Power Output (8 ohm, 20 Hz - 20 kHz, 0.08% 2ch Drive) 100 W
Power Output (8 ohm, 20 Hz - 20 kHz, 0.05% 2ch Drive) No
Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive) 120 W
Power Output (6 ohm, 1 kHz, 10% 1ch Drive) 175 W

General

Metal Front Panel No
System Remote Control RC-1235
Pre-programmed / Learnable / LCD Display No / No / No
Power Consumption in W TBD
Power Consumption No-Sound (ECO On / Off) in W TBD
Standby Consumption in W 0.1
CEC Standby Consumption in W 0.5
Maximum Dimensions
Antenna: Horizontal: (W x D x H) in Inches
Antenna: Vertical: (W x D x H) in Inches
W/O Antenna: (W x D x H) in Inches 17.1× 13.3 × 6
( 17.1 x 13.3 x 8.5)
Weight in LBS 18.3
Power Supply AC 120 V, 60 Hz
Speaker impedance 4 - 16Ω/ohms
Input sensitivity 200 mV
Frequency response 10 Hz - 100 kHz — +1, –3 dB (Direct mode)
S/N Ratio 98 dB (IHF-A weighted, Direct mode)
FM section (Tuning frequency range) 87.5 - 107.9 MHz
AM section (Tuning frequency range) 520 kHz – 1710 kHz
