PMA-A110
PMA-A110
PMA-A110
PMA-A110
PMA-A110
PMA-A110
PMA-A110
PMA-A110
PMA-A110
PMA-A110
PMA-A110
PMA-A110
PMA-A110
PMA-A110

PMA-A110

Limited 110th Anniversary Edition 2 Ch. 80W Integrated Amplifier

The Denon limited series Anniversary Edition silver graphite PMA-A110 integrated amplifier delivers best in class audio performance for a best in class audio experience.

  • Stereo amplifier
  • 80W per channel (8 ohms)
  • AL32 Processing
  • Quad DAC Configuration
  • Precise electrical controls
  • MM/MC phono
Color
Grey
Grey
PMA-A110
Details & Specifications
  • Channels 2
  • 110th Anniversary Audio Tuning Yes
  • All black interior Yes
  • Exclusive A110 speaker terminals Yes
  • Aluminium Top Cover Yes
  • Aluminium Feet Yes
  • Digital in: USB-B / optical / coaxial / USB-A 1 / 3 / 1 / No
  • Sample Rate digital In 192 kHz / 24-bit
  • USB-B DSD Audio Streaming (DoP): DSD2.8 / DSD5.6 <=DSD11.2
  • USB-B PCM sample rate 384 kHz / 32-bit
  • Quad DAC Configuration Yes
  • DAC chip 4x PCM1795, Burr Brown
    Mono-Mode
  • Asynchronous mode rear USB Yes
  • Bit-perfect transmission Yes
  • Ground isolator for DAC Mode operation Yes
  • AL 32 Processing ULTRA AL32
  • DAC Master Clock Design Yes
  • Streaming audio from PC Yes
  • Analogue Mode Yes
  • UHC-MOS single push pull circuit 7th Generation
  • LC mounted twin transformer Yes
  • Wide range amplifier Yes
  • High current dynamic power supply Yes
  • Power amp discrete construction Yes
  • Balance / Bass / Treble / Loudness Yes / Yes / Yes / No
  • Shottky diodes Yes
  • Solid Heat Sinks Yes (BLACK)
  • Source Direct Yes
  • Power Amp direct Yes
  • Audio Inputs 5
  • Digital in: USB-B / optical / coaxial / USB-A 1 / 3 / 1 / No
  • Phono Input: MM / MC Yes / Yes
  • Audio Outputs 1
  • Power Amp Direct IN Yes
  • Gold plated Cinch Yes
  • Number of terminals 4
  • Remote Control Bus in / out Yes
  • Headphone Out Yes
  • Output power 8 Ohm (20 Hz - 20 kHz, T.H.D. 0.07%) 80 W
  • Output power 4 Ohm (1 kHz, T.H.D. 0.7%) 160 W
  • Total Harmonic Distortion 0.01%
  • Input Sensitivity: MM 2.5 mV / 47 kohm
  • Input Sensitivity: MC 200 uV-100 ohm
  • Signal to Noise Ratio: MM/MC 89 dB / 74 dB
  • Input Sensitivity: High level 135 mV / 47 kohms
  • Signal to Noise Ratio: High level 110dB
  • Treble Control ± 8 dB at 10 kHz
  • Bass Control ± 8 dB at 100 Hz
  • Available colors: Premium Silver / Black Silver Graphite
  • Metal Front Panel Yes
  • Power Consumption in W 400
  • Standby Consumption in W 0.2
  • Auto Power Off Yes
  • Detachable Power Cable Yes
  • Remote Control RC-1237
  • System Remote Function Yes
  • Maximum Dimensions (W x D x H) in mm 434ｘ450ｘ182
  • Weight in kg 25
  • Carton Maximum Dimensions (W x D x H) in Inches 573 x 533 x 317
  • Carton Weight (inc. product) in LBS 29.8
