PMA-1600NE

2 Ch. 140W integrated Amplifier

Featuring advanced UHC single-push-pull circuit power, Advanced AL32 Processing and MM/MC phono equalizer, the Denon PMA-1600NE integrated amplifier delivers extraordinary sound quality with precise detail.

Stereo amplifier
70W per channel (8 ohms)
AL32 Processing
USB-DAC
Digital inputs
MM/MC phono

Select Quality

Colour

Black Silver

Black

PMA-1600NE

Details & Specifications

Owner’s Manual

Features

Channels 2
UHC-MOS single push pull circuit Yes (Advanced)
LC mounted twin transformer Yes
Wide range amplifier Yes
High current dynamic power supply Yes
Power amp discrete construction Yes
Micro processor auto off Yes
Solid Heat Sinks Yes (Separate)
Source Direct Yes
Balance / Bass / Treble / Loudness Yes / Yes / Yes / No
Digital in: USB-B / optical / coaxial / USB-A Yes / 2 / 1 / No
Sample Rate digital In 192 kHz / 24-bit
USB-B DSD Audio Streaming (DoP): DSD2.8 / DSD5.6 11.2
USB-B PCM sample rate 384 kHz / 32-bit
DAC chip PCM1795
Asynchronous mode rear USB Yes
Bit-perfect transmission Yes
AL 32 Processing Advanced AL32 Plus
DAC Master Clock Design Yes
Streaming audio from PC Yes
Analogue Mode Yes

Inputs Outputs

Audio Inputs 4
Phono Input: MM / MC Yes / Yes
Audio Outputs 1
Gold plated Cinch Yes
Number of terminals 2
Remote Control Bus in / out Yes
Headphone Out Yes
Digital in: USB-B / optical / coaxial / USB-A Yes / 2 / 1 / No

Specifications

Output power 8 Ohm (20 Hz - 20 kHz, T.H.D. 0.07%) 70 W
Output power 4 Ohm (1 kHz, T.H.D. 0.7%) 140 W
Total Harmonic Distortion 0.01%
Input Sensitivity: MM 2.5 mV / 47 kohm
Input Sensitivity: MC 200 uV / 100 ohm
Signal to Noise Ratio: MM/MC 89 dB / 74 dB
Input Sensitivity: High level 125 mV / 47 kohms
Signal to Noise Ratio: High level 108dB
Treble Control ± 8 dB at 10 kHz
Bass Control ± 8 dB at 100 Hz

General

Available colors: Premium Silver / Black Yes / Yes
Metal Front Panel Yes
Power Consumption in W 295
Standby Consumption in W 0.2
Auto Power Off Yes
Detachable Power Cable Yes
Remote Control RC-1213
System Remote Function Yes
Maximum Dimensions (W x D x H) in mm 434 x 414 x 135
Weight in kg 17.6
